BLUETTI B500K Expansion Battery | 5120Wh
Overview
The BLUETTI B500K is a 5120Wh LiFePO4 expansion battery that adds stored capacity to a compatible BLUETTI power station, extending its runtime for home backup, off-grid living, motorhomes, and long NZ winter outages. It is an add-on battery, not a standalone unit: it stores energy for a host power station and does not provide AC output on its own.
The cells are LiFePO4, rated for 4000+ cycles to 80 percent of their original capacity, so the pack is built to last through years of daily use. The B500K connects to its host with the included CA90 short cable, and multiple units stack to build a much larger system (BLUETTI rates a full multi-host setup to over 100kWh). It is the current-generation replacement for the discontinued B300S.
BLUETTI B500K Specs:
- Capacity: 5120Wh
- Cell Chemistry: LiFePO4 (Lithium Iron Phosphate)
- Cycle Life: 4000+ cycles to 80 percent of original capacity
- Weight: 45kg
- Dimensions: 520 x 327 x 308.5mm
- Expansion Ports: 2 x expansion port, 58.4V DC max, 90A max
- Charging Current: 65A max
- Discharging Current: 70A max
- Charging Temperature: 0°C to 40°C
- Discharging Temperature: -20°C to 40°C
- Storage Temperature: -20°C to 40°C (up to 1 month); -20°C to 25°C (up to 6 months)
- Working Humidity: 5 percent to 95 percent RH
- Enclosure Rating: IP20 (indoor use)
- Monitoring: BLUETTI app
What's in the Box?
- 1 x BLUETTI B500K Expansion Battery
- 1 x Battery Expansion Cable (CA90 Short Cable)
- 1 x User Manual
- Download the BLUETTI B500K user manual (PDF)
- Warranty: 4-year warranty
Note: The B500K is an expansion battery, not a standalone unit. It stores energy for a compatible BLUETTI power station, which is sold separately.
Compatible Across the BLUETTI Range
The B500K expands a range of BLUETTI power stations rather than a single model. It works with the Apex 300, AC500, AC300, AC200MAX, and AC200L, so an existing system can be grown without replacing the power station you already own.
Compatibility is host-dependent. Confirm your exact power station and how many batteries it supports with us before ordering.
LFP Cells Built for Safety and Longevity
The B500K uses LiFePO4 cells rated for 4000+ cycles to 80 percent capacity, a chemistry chosen for stability and a long service life. A cable-free internal layout reduces failure points, and the pack manages its own temperature within a wide operating range for reliable use through a NZ winter or a hot summer bach.
Fixed or Movable
Set the B500K up as a permanent part of a home-backup system or move it where the power is needed. It is wall-mount ready with a screw-in design for a tidy fixed install, and it stacks with its host for a compact footprint.
Pairs Well With
The B500K is built to expand compatible BLUETTI power stations. It pairs with the BLUETTI Apex 300 to extend that system's backup and off-grid runtime, and is also compatible with the AC500, AC300, AC200MAX, and AC200L.
Frequently Asked Questions
Does the B500K work on its own?
No. The B500K is an expansion battery, not a standalone power station. It stores energy for a compatible BLUETTI power station and does not provide AC output by itself. You need a compatible host, which is sold separately.
Which power stations does it work with?
The B500K is compatible with the BLUETTI Apex 300, AC500, AC300, AC200MAX, and AC200L. The number of batteries a system supports depends on the host, so please confirm your setup with us before ordering.
What cable is included?
The B500K ships with the CA90 short cable, which connects the battery to a compatible BLUETTI power station. No separate expansion cable needs to be purchased for a standard single-battery connection.
How much does it add, and can I stack more than one?
Each B500K adds 5120Wh. Multiple units stack to expand a system further, and a full multi-host BLUETTI setup scales to over 100kWh. The exact number your host supports varies, so confirm the limit for your power station with us.
Does it replace the B300S?
Yes. The B500K is the current-generation replacement for the discontinued B300S, with a larger 5120Wh capacity and LiFePO4 cells rated for 4000+ cycles.
What warranty does it come with?
The B500K comes with a 4-year warranty in New Zealand, handled through us as the distributor. There is no registration step required to receive the full term.
